Introduction to Verilog: Designing the Digital World

Verilog is a hardware description language (HDL) used to model electronic systems. It plays a crucial role in the design and verification of digital circuits, ranging from simple logic gates to complex microprocessors and System on Chips (SoCs). Think of it as a way to describe the behavior and structure of digital hardware, much like programming languages describe the behavior of software. With Verilog, engineers can design, simulate, and synthesize digital circuits before they are physically created, saving time and resources.

Working with Verilog can be engaging for several reasons. Firstly, it allows you to be at the forefront of technological innovation, designing the chips that power everything from smartphones and computers to automotive systems and medical devices. Secondly, the process of translating an idea into a functional digital circuit using Verilog involves a satisfying blend of creativity and logical problem-solving. Finally, the ability to simulate and verify your designs provides immediate feedback and the opportunity to refine your creations, leading to a deep understanding of digital electronics.

What Exactly is Verilog?

At its core, Verilog is a language that allows engineers to describe digital hardware at various levels of abstraction. This means you can define a circuit by its behavior (what it does), its dataflow (how data moves through it), or its structure (how basic components are interconnected). This flexibility is one of Verilog's key strengths.

Imagine you want to build a simple traffic light controller. Using Verilog, you could describe the sequence of lights (red, yellow, green), the timing for each light, and the conditions for changing states. This behavioral description can then be simulated to ensure it works correctly before any actual hardware is built. Subsequently, synthesis tools can translate this Verilog code into a netlist, which is essentially a blueprint of interconnected logic gates that can be implemented on a Field-Programmable Gate Array (FPGA) or an Application-Specific Integrated Circuit (ASIC).

A Brief History and Standardization

Verilog was created by Prabhu Goel, Phil Moorby, and Chi-Lai Huang between late 1983 and early 1984. Initially, it was a proprietary language developed at Gateway Design Automation. Recognizing its potential and the growing need for a standardized HDL, Cadence Design Systems, which acquired Gateway in 1990, placed Verilog into the public domain in 1991 through the Open Verilog International (OVI) organization (now Accellera).

This move paved the way for Verilog to become an industry standard. It was subsequently submitted to the Institute of Electrical and Electronics Engineers (IEEE) and became IEEE Standard 1364-1995, commonly known as Verilog-95. Over the years, the standard has been revised and enhanced to address the evolving needs of the industry. Significant updates include Verilog-2001 (IEEE 1364-2001) and Verilog-2005 (IEEE 1364-2005). Eventually, Verilog was merged with SystemVerilog, a more extensive language offering advanced verification features, to create IEEE Standard 1800. The current version is IEEE 1800-2023.

Key Industries and Applications

Verilog is a cornerstone in several key industries. The most prominent is the semiconductor industry, where it is extensively used for designing ASICs and FPGAs. These chips are the brains of countless electronic devices.

Other significant applications include:

Embedded Systems: Designing hardware components like microcontrollers and specialized processors within larger systems.
Digital Signal Processing (DSP): Implementing algorithms in hardware for applications such as audio and video processing.
Networking: Creating the hardware for routers, switches, and network interface cards.
Automotive: Developing electronic control units (ECUs) and advanced driver-assistance systems (ADAS).
Aerospace and Defense: Building sophisticated electronics for communication, navigation, and control systems.

Verilog vs. Other Hardware Description Languages

While Verilog is a dominant HDL, it's not the only one. The other major player is VHDL (VHSIC Hardware Description Language). Both Verilog and VHDL serve similar purposes but have different origins and syntactical styles.

Verilog's syntax is often compared to the C programming language, which can make it feel more approachable for those with a C background. It is generally considered more concise than VHDL. VHDL, on the other hand, has a syntax inspired by the Ada programming language and is known for being more verbose but also more strongly typed, which can help catch errors early in the design process. VHDL is sometimes favored in defense and aerospace industries, while Verilog sees extensive use in the broader semiconductor industry.

Ultimately, the choice between Verilog and VHDL can come down to project requirements, industry conventions, team expertise, or even personal preference. Many engineers find it beneficial to be familiar with both. More recently, SystemVerilog, an extension of Verilog, has gained widespread adoption, particularly for complex verification tasks, offering more powerful features than both traditional Verilog and VHDL.

For individuals starting their journey in hardware design, understanding these differences can help in choosing the right learning path. The good news is that the core concepts of digital design are transferable between these languages.

Verilog Key Concepts and Syntax

To effectively use Verilog, it's essential to grasp its fundamental concepts and syntax. Verilog allows designers to describe hardware in a structured and hierarchical manner, much like breaking down a complex system into smaller, manageable parts.

Modules and Hierarchical Design

The basic building block in Verilog is the module. A module encapsulates a piece of digital logic, defining its inputs, outputs, and internal behavior or structure. Think of a module as a black box with a specific function. For instance, you could have a module for an adder, a multiplexer, or even an entire microprocessor.

Verilog promotes hierarchical design, meaning complex systems are built by instantiating (creating instances of) modules within other modules. This is akin to assembling a car from various components like the engine, chassis, and wheels, where each component itself might be made of smaller sub-components. This approach makes designs easier to manage, understand, and reuse.

Here is a very simple example of a Verilog module for an AND gate:


module and_gate (
  input  a,
  input  b,
  output out
);

  assign out = a & b;

endmodule

In this example, and_gate is the module name. It has two inputs, a and b, and one output, out. The line assign out = a & b; describes the behavior of the AND gate: the output out is the logical AND of inputs a and b.

Data Types and Operators

Verilog supports various data types to represent signals in a digital circuit. The most common are wires and regs. A wire is used to represent a physical connection between components and cannot store a value (it must be continuously driven). A reg (register) can store a value and is typically used within behavioral blocks, such as always blocks, to represent storage elements like flip-flops or memory.

Verilog offers a rich set of operators similar to those found in C. These include:

Logical operators: AND (&&), OR (||), NOT (!)
Bitwise operators: AND (&), OR (|), XOR (^), NOT (~)
Arithmetic operators: Add (+), Subtract (-), Multiply (*), Divide (/), Modulus (%)
Relational operators: Greater than (>), Less than (<), Equal to (==), Not equal to (!=)
Shift operators: Left shift (<<), Right shift (>>)
Concatenation operator: { } (used to combine bits)
Conditional operator: ? : (ternary operator)

Signals in Verilog can represent four basic values:

0: Logic zero, or a false condition.
1: Logic one, or a true condition.
x: An unknown logic value (e.g., an uninitialized register or a conflicting output).
z: A high-impedance state (e.g., a tri-state buffer output that is not driving).

Numbers can be specified in binary, octal, decimal, or hexadecimal format.

Simulation vs. Synthesis Constructs

Verilog contains constructs that are intended for simulation (verifying the design's behavior) and constructs that are intended for synthesis (translating the design into actual hardware). It's crucial to understand this distinction.

Synthesizable constructs are those that can be directly mapped to physical hardware components like logic gates, flip-flops, and memories. Examples include most behavioral descriptions using always blocks with sensitivity lists (e.g., always @(posedge clk) for synchronous logic or always @(*) for combinational logic), assign statements for continuous assignments, and instantiations of other synthesizable modules. The goal of writing synthesizable code is to describe hardware that can be physically realized.

Non-synthesizable constructs are primarily used for creating test environments (testbenches) or for modeling abstract behavior that doesn't directly translate to hardware. Examples include initial blocks (initial), delays (#10), system tasks like $display (for printing messages during simulation) and $finish (for ending a simulation), and file I/O operations. While vital for verification, these constructs are generally ignored or may cause errors during the synthesis process if used within the design intended for hardware implementation.

For example, an initial block is often used in a testbench to set up initial conditions or apply a sequence of input stimuli:


initial begin
  clk = 0;
  reset = 1;
  #10 reset = 0; // Apply reset for 10 time units
  #20 data_in = 4'b0001;
  #10 data_in = 4'b0010;
  // ... more stimuli
  #100 $finish; // End simulation after 100 time units
end

This block is perfect for simulation but wouldn't be part of the actual hardware design being synthesized.

Testbenches and Verification Methodologies

Verification is a critical part of the hardware design process, ensuring that the designed circuit behaves as intended under various conditions. A testbench is a Verilog module written specifically to test another Verilog module (the "design under test" or DUT).

The testbench typically performs the following functions:

Instantiates the DUT.
Generates input stimuli (signals and data) to drive the DUT's inputs.
Monitors the DUT's outputs.
Compares the actual outputs with expected outputs.
Reports any discrepancies or errors.

Writing effective testbenches is as important as writing the design itself. Simple testbenches might manually apply a few test vectors, while more complex ones can use procedural loops, random stimulus generation, and self-checking mechanisms. As designs have grown in complexity, more advanced verification methodologies have emerged, such as the Universal Verification Methodology (UVM), which is often implemented using SystemVerilog. These methodologies provide frameworks and libraries for creating robust, reusable, and scalable verification environments.

The following courses can provide a solid foundation in Verilog and its application in FPGA design.
